Key Specs
1895
sq ft
3
Beds
2
Baths
1
Floors
2
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 17-2903
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 86'
Height : 19' 6"
Width : 35'
Area
First Floor: 1895 sq/ft height 9'
Garage: 534 sq/ft
Porch: 307 sq/ft
Roof
Primary Pitch : 8:12
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Garage Features
Rear Entry Garage
Outdoor Spaces
Courtyard
Covered Front Porch
Rooms
Bathroom 2:
111 sq/ft width 13' 4" x depth 8' 4"
Bedroom 2:
151 sq/ft width 13' 4" x depth 11' 4"
Courtyard:
292 sq/ft width 15' 8" x depth 18' 8"
Covered Porch:
173 sq/ft width 21' 8" x depth 8'
Den/Office or Bedroom 3:
159 sq/ft width 13' 4" x depth 12'
Dining Room:
211 sq/ft width 18' 8" x depth 11' 4"
Foyer:
92 sq/ft width 7' x depth 13' 2"
Garage:
461 sq/ft width 20' 8" x depth 22' 4"
Garage Storage:
22 sq/ft width 6' 6" x depth 3' 6"
Great Room:
330 sq/ft width 20' 8" x depth 16'
Kitchen:
143 sq/ft width 13' 8" x depth 10' 6"
Laundry Room:
46 sq/ft width 8' 8" x depth 5' 4"
Master Bathroom:
186 sq/ft width 13' 4" x depth 14'
Master Suite:
195 sq/ft width 13' 4" x depth 14' 8"
Storage:
22 sq/ft width 6' 6" x depth 3' 6"
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$800.00
$900.00
$1150.00
$1500.00
$1600.00
$1600.00
Foundation
$0.00
$0.00
Framing
$0.00
$299.00
Additional Options
$299.00
$80.00
$100.00
$295.00
$39.00
$149.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
