PLAN 1010-28
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 60'
Height : 24' 8"
Width : 55'
Area
Bonus: 290 sq/ft
First Floor: 1903 sq/ft
Garage: 528 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Asphalt
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Shingle
Framing : Wood - 2x6
Bedroom Features
Formal Dining Room
Walk In Closet
Kitchen Features
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Mud Room
Storage Area
Vaulted / Cathedral Ceilings
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bedroom 2:
133 sq/ft width 12' 2" x depth 11'
Bedroom 3:
122 sq/ft width 11' 2" x depth 11'
Dining Room:
164 sq/ft width 13' 8" x depth 12'
Garage:
528 sq/ft width 24' x depth 22'
Great Room:
315 sq/ft width 21' x depth 15'
Hearth Room:
110 sq/ft width 11' x depth 10'
Kitchen:
139 sq/ft width 12' 10" x depth 10' 10"
Master Bedroom:
232 sq/ft width 15' 4" x depth 15' 2"
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Roof Plan: ?” scale; this shows roof rafter or trusses and how the roof is framed.
- CAD Plans are in AutoDesk Architecture.
Plan Set
$1300.00
$1350.00
$2600.00
$800.00
$800.00
Foundation
$0.00
Framing
$0.00
Additional Options
$75.00
$165.00
$295.00
$39.00
$165.00
$100.00
