Key Specs
1912
sq ft
4
Beds
2
Baths
1
Floors
2
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 513-2128
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 54'
Height : 26'
Width : 65' 6"
Area
First Floor: 1912 sq/ft
Garage: 571 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Kitchen Features
Breakfast Nook
Additional Room Features
Sunroom
Outdoor Spaces
Covered Front Porch
Screened Porch
Rooms
Bathroom 2:
56 sq/ft width 11' x depth 5' 2"
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
143 sq/ft width 11' x depth 13'
Bedroom 4:
132 sq/ft width 12' x depth 11'
Dining Room:
132 sq/ft width 12' x depth 11'
Garage:
484 sq/ft width 22' x depth 22'
Kitchen:
140 sq/ft width 11' x depth 12' 9"
Living Room:
333 sq/ft width 16' 8" x depth 20'
Master Bathroom:
85 sq/ft width 9' x depth 9' 6"
Master Bedroom:
192 sq/ft width 12' x depth 16'
Master Closet:
54 sq/ft width 9' x depth 6'
Nook:
121 sq/ft width 11' x depth 11'
Porch - Screened:
166 sq/ft width 16' 8" x depth 10'
Utility Room:
41 sq/ft width 7' 6" x depth 5' 6"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
Plan Set
$1005.00
$1300.00
Foundation
$0.00
$195.00
$195.00
Framing
$0.00
$195.00
Additional Options
$195.00
$165.00
$295.00
$39.00
$165.00
*Alternate Foundations may take time to prepare.
