PLAN 320-1004
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 51'
Height : 30'
Width : 66'
Area
Basement Unfinished: 1266 sq/ft
First Floor: 1266 sq/ft
Garage: 700 sq/ft
Second Floor: 1210 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Mud Room
Upstairs Laundry
Vaulted / Cathedral Ceilings
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
132 sq/ft width 11' x depth 12'
Bedroom 4:
143 sq/ft width 11' x depth 13'
Dinette:
176 sq/ft width 11' x depth 16'
Dining Room:
143 sq/ft width 11' x depth 13'
Garage:
960 sq/ft width 40' x depth 24'
Great Room:
238 sq/ft width 17' x depth 14'
Hearth Room:
130 sq/ft width 10' x depth 13'
Study:
87 sq/ft width 9' 3" x depth 9' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$860.00
$1720.00
Foundation
$0.00
Framing
$0.00
Additional Options
$100.00
$39.00
$100.00
$50.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
