Key Specs
2622
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-1201
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 48'
Height : 33' 10"
Width : 40'
Area
First Floor: 1219 sq/ft height 10'
Garage: 524 sq/ft
Second Floor: 1403 sq/ft height 8'
Ceiling
Ceiling Details : Entry 2-Story, Master Bdrm 9' Tray.
Lower Ceiling : 8'
Main Ceiling : 10'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2x6
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Unfinished Future Space
Upstairs Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Rooms
Bath 2:
63 sq/ft width 12' 8" x depth 5'
Bedroom 2:
177 sq/ft width 14' 4" x depth 12' 4"
Bedroom 2 Closet:
15 sq/ft width 2' x depth 7' 8"
Bedroom 3:
140 sq/ft width 11' 4" x depth 12' 4"
Bedroom 3 Closet:
14 sq/ft width 7' x depth 2'
Covered Front Porch:
104 sq/ft width 15' 8" x depth 6' 8"
Dining Room:
208 sq/ft width 16' 8" x depth 12' 6"
Foyer:
76 sq/ft width 7' 4" x depth 10' 4"
Garage:
524 sq/ft width 23' 4" x depth 21' 8"
Great Room:
425 sq/ft width 22' x depth 19' 4"
Half Bath:
32 sq/ft width 6' x depth 5' 4"
Hallway:
66 sq/ft width 6' x depth 11'
Kitchen:
208 sq/ft width 16' 8" x depth 12' 6"
Laundry:
128 sq/ft width 16' 8" x depth 7' 8"
Master Closet:
70 sq/ft width 7' x depth 10'
Master Bath:
93 sq/ft width 9' 4" x depth 10'
Master Bedroom:
412 sq/ft width 21' 8" x depth 18'
Pantry:
27 sq/ft width 5' x depth 5' 4"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1100.00
$1163.00
$1394.00
$1394.00
$2217.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$295.00
$39.00
$75.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
