Key Specs
3318
sq ft
2
Beds
2.5
Baths
2
Floors
0
Garages
Phone: 1-866-445-9085
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 117-561
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 64' 6"
Height : 22' 8"
Width : 69'
Area
Attic: 360 sq/ft
Basement Living: 1659 sq/ft
First Floor: 1659 sq/ft
Garage: 836 sq/ft
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 7:12
Roof Framing : Truss
Secondary Pitch : 11:12
Exterior Wall Framing
Exterior Wall Finish : Shingle/Siding
Framing : Concrete block
Bedroom Features
Main Floor Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Mud Room
Storage Area
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
More
Suited For Vacation Home
Rooms
Bedroom 2:
235 sq/ft width 17' 8" x depth 13' 4"
Dining Room:
132 sq/ft width 13' 8" x depth 9' 8"
Family Room:
596 sq/ft width 19' x depth 31' 5"
Foyer:
112 sq/ft width 8' 8" x depth 13'
Garage:
801 sq/ft width 27' 4" x depth 29' 4"
Great Room:
357 sq/ft width 19' x depth 18' 10"
Kitchen:
199 sq/ft width 14' x depth 14' 3"
Master Bathroom:
107 sq/ft width 13' 8" x depth 7' 10"
Master Suite:
230 sq/ft width 13' 8" x depth 16' 10"
Mechanical/Equipment Room:
129 sq/ft width 13' 8" x depth 9' 6"
Mud Room:
97 sq/ft width 13' 8" x depth 7' 2"
Office:
111 sq/ft width 10' x depth 11' 2"
Sitting Area:
252 sq/ft width 13' 8" x depth 18' 6"
Storage:
166 sq/ft width 13' 8" x depth 12' 2"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1395.00
$1495.00
$1495.00
$1645.00
$2195.00
Foundation
$0.00
Additional Options
$195.00
$50.00
$165.00
$395.00
$39.00
$165.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
