PLAN 45-602
Photographs may show modified designs.
- Jump to:
- All (11)
- Floor plans (3)
Get Personalized Help
Key Specs
1550
sq ft
3
Beds
2.5
Baths
2
Floors
0
Garages
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-866-445-9085
Phone: 1-866-445-9085
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern
See our Terms & Conditions and Privacy Policy.
Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 45-602
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-866-445-9085 for assistance.
Plan Description
MOUNTAIN SIDE LOG HOME This darling log cabin has a small footprint which can be built on a very small lot but the small size is packed with larger home features. A covered front porch welcomes guest and opens into the impressive living room space with sloped ceilings that slopes to member with the ceilings of the upper level ceilings. That allows the rear upper level bed room to have a balcony that overlooks the living room below making the space open and airy. Of course, the plan is pre-designed to allow for a wall in lieu of the railing for those that want to privatize the upper level bed room. An additional bed room is located on the front and features clipped ceilings for added coziness. A centrally located full size bath serves the two secondary bedrooms and a study in between makes the upper level ideal for students. Descend to the Main Level via a stairwell with open areas that allows for a view of the main level living spaces as you make your way to the living room. An island design kitchen is open to the living room as is the dining area making the space seem much larger than it actually is. The kitchen island features a raised bar which adds to the dining capacity. The living spaces have maximum glass area to make the living areas even more open and airy. The small alcove leading into the Master Suite from the living spaces conceals an entrance into a guest bath and a stairwell down to the basement. The basement can be finished to add a live in parent’s suite, extra living space, or a game room – the possibilities are endless.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Floor Plan - Lower Floor
Full Specs & Features
Dimension
Depth : 46'
Height : 27'
Width : 32'
Area
Basement : 1073 sq/ft
Main Floor : 1073 sq/ft
Porch : 238 sq/ft
Upper Floor : 477 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Living room ceiling slopes from 9' to member with upper level ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 12:12
Roof Framing : conventional
Exterior Wall Framing
Exterior Wall Finish : logs and cultuired stone
Framing : 6x12 logs
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Loft
Main Floor Laundry
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Suited For Vacation Home
What's Included In This Plan Set
- Information Cover Sheet
- Foundation Plan: Each plan is designed on a specific type of foundation. Optional foundation types may be offered. Refer to the general information listed with each plan to determine foundation type and options available.
- Detailed Floor Plans: Complete with the window and door schedules. Electrical plans, with suggested switch, fixture and outlet locations, may be part of the floor plan or a separate drawing.
- Exterior Views
- Building Sections & Interior Elevations
- Complete Construction Details
- Complete Specifications: Specifications list the types of materials used in the construction of the home. Finish schedules are provided.
Questions? Call 1-866-445-9085
Plan Set
PDF Set:
$1000.00
$1000.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set:
$1130.00
$1130.00
5 printed plan sets mailed to you.
8 Copy Set:
$1240.00
$1240.00
8 printed plan sets mailed to you.
5 Copy and PDF Set:
$1255.00
$1255.00
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set:
$1900.00
$1900.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Foundation
Basement:
$0.00
$0.00
Ideal for level lot, lower level of home partially or fully underground.
Walk Out Basement:
$0.00
$0.00
Ideal for a sloping lot, lower level with outdoor access.
Framing
Log:
$0.00
$0.00
True Log Plan: Uses logs instead of exterior framing
Additional Options
Right-Reading Reverse:
$150.00
$150.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
$45.00
$45.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$100.00
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
$39.00
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Mirror Reversed Sets:
$75.00
$75.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
